Low Cost Digital Pressure Gauge Supplier

We are a foremost supplier, trader & exporter of CE approved and full safety pattern (EN387-1) Low Cost Digital Pressure Gauge, based in Gujarat, India.

This low cost digital pressure gauge is attentively configured by concentrating some specific industrial requirement incorporating hydraulics and pneumatics. Due to its cost efficiency factor, this digital pressure gauge is famed as low cost digital pressure gauge in several industries, known for its easy to install and easy to read traits worldwide. This low cost digital pressure gauge can be operated using three push buttons smoothly.

low cost digital pressure gauge

Technical side of the Low Cost Digital Pressure Gauge:

Case Size 2.5″ (63mm)
Case Material ABS (1P64)
Rubber Boot Silicone rubber (1P65)
LCD Display 2″ x 3/4″ (48mm x 16mm)
Connection 1/4H NFT 304S5
Sensor 316L welded, Piezo
Operation Life 1 million cycles
Power Supply 2x AAA battery (1.5V)
Battery Life 2 yrs (auto shut-off mode)
Power Mode Auto or manual shut-off
Display Digits 4 digits to 5,000 psi 5 digits for 10,000 psi
Resolution Digit
Pressure Unit Selection psi, MMH2o mmhg, mbar, KPa≤ 100 psi Psi, bar, kg/cm2, mPa, atm ranges≥160 psi
Operation Mode Continuously reading or peak pressure reading
Response Time ≤3 Hz display refresh rate
Proof Burst Pressure 200% 300% fS
Operating Storage Temperature 14c˚ F to 122˚F (-10˚C to 50°C) -4˚F to 167°F (-20˚C to 75°C)
Accuracy ± 0.5%

We as a supplier, trader and exporter of the pressure gauge have indulged ever since an elongated time, which has rewarded us with the profound expertise for the same. By leveraging the same, we have associated with the certified low cost pressure gauge manufacturer who ensures the quality, reliability and safety of their end product. Further, in order to confirm its conformity with the set industrial standards, we execute certain significant tests on the same earlier to the final dealing with the respective vendor. Thereby, we strongly assure the quality and reliability of the offered product to you.

This low cost digital pressure gauge boasts constantly rotatable display module in order to ensure the convenience and clear readability of the pressure readings, and thus is also preferable for the awkward installation position. The touchpad embraces total three push buttons for operating this low cost digital pressure gauge, with the help of this one can get the nominal pressure range, minimum, maximum pressure range in the different pressure units covering bar, mbar, psi, MWC, inHg, cmHg, mmHg, kPa, MPa & Kg/Cm2. Moreover, the decimal point is also can be set by the operator using this push buttons effortlessly.

In respect to the variegated demand of the several industries in terms of specification, we as supplier, trader and exporter of this low cost pressure gauge have made it available in the extensive range. The available range of this low cost pressure gauges made of the ABS material that imparts excellent strength and rigidity to the gauge and thus helps withstand rigorous temperature environments effectively. The LCD display and adequate light of this low cost pressure gauge aids to get the most accurate reading, recommended for commercial and industrial applications for testing purposes as well as installation purposes.
