Bourdon Tube Pressure Gauge Supplier

We are a foremost supplier, trader & exporter of CE approved and full safety pattern (EN387-1) Bourdon Tube Pressure Gauge, based in Gujarat, India.

The bourdon tube pressure gauges are the best approach to measure the relative pressure from 0.6 to 7 k bar, is one of the mechanical pressure measuring instruments that does not require electrical power for the functioning. The liquid filled case of these bourdon tube pressure gauges are distinctly commended for applications with high dynamic pressure liquid media in order to deliver reliable measured value display in the movement. We as a supplier, trader and exporter of such a highly praised pressure gauge recommend it for corrosive environments as well as gaseous environment where there is no obstruct in the pressure system.

bourdontube pressure gauge
Principle options available in commercial pressure gauge:
Dial 4" (100 mm.), 6" (150 mm.), 8" (200 mm.), white aluminu
Pointer Black aluminum, fixed or adjustable. Wide selection of connections and pressure ranges. Crimped ring or bayonet bezel
Accuracy 4", 6", & 8" : ± 1.0% (± 1.6% with filling)

The technical ingeniousness and close cooperation of a team of dexterous professionals in order to carry out incredible solution for the respective application need is one of the reasons for thriving success in the allied industry. The cautiousness toward quality standards together with the profound understanding of the functionality of the bourdon tube pressure gauges has backed us in selecting the finest quality bourdon tube pressure gauges from the licensed vendors. Further, the conformity of the quality measures is ensured with by precisely inspecting of each unit in prior to finalizing deal.

Basically, this bourdon tubes used in the pressure gauge are tubes with an oval cross section. The pressure of measuring medium functions on the inside of the tube and develop a motion in the non clamped end of the tube. This motion is a measure of the pressure and is signified via the movement. The offered bourdon tube pressure gauge can be used for pressure up to 60 bar, wherein the limit of the pressure can be amplified by superimposing winding of the same angular diameter.

We as a supplier, trader and exporter of the bourdon tube pressure gauges make it available in different specification ranges, wherein the case of the pressure gauge is made of the proven quality stainless steel material. These bourdon tube pressure gauges are broadly acclaimed in the several industries for sharing exclusive features incorporating excellent Repeatability, excellent Hysteresis, less maintenance, corrosion resistance, moisture resistance, accurate measurements even in the critical conditions. Such a highly featured bourdon tube pressure gauge finds application in Chemical / Petrochemical, Power Station, Mining, on and off shone, environmental technology, mechanical engineering and plant construction segments.

Technical side of the Bourdon Tube Pressure Gauge

Nominal Size (mm) 40,50,63,80,100,150 ,250 mm
Scale Range 0 Vacuum to 700 kg/cm2 & above on request
Accuracy in FSD 1%
Thread Connection 1/1/8″ , 1/4″, 3/8″, ½ " BSP NPT, M-10, M-12, M-20
Case and Bezel Draw n steel, SS 304
Pressure Elements Bourdon Tube
Diaphragm Nil
Wetted Parts Brass, SS 304
Mounting of Gauge Bottom, Surface, Back, Panel with 3 holes, Panel with bracket
Optional Liquid Filled
